3Overview
18 CyFlow
®
Cube 8 | Operating Manual | May 2018 | Revision 032
3.2 Type plate
The type plate is attached to the rear side of the device.
The content of the type plate varies according to the system configuration.
The system configuration is represented by an addition to the REF number
(e.g. CY-S-3068R_N1).
The following signs are part of the type plate which has been affixed to the device.
Symbol Meaning
For Research Use Only
Manufacturer
Certification mark
Reference Number
Serial Number
Manufacturing date
Waste of Electrical and Electronic Equipment
Operating manual
Indicates the temperature limits to which the device can be
safely exposed
No direct sunlight at the installation location
Indicates the range of relative humidity to which the device
can be safely exposed
Caution
RUO
