12 Software description
74 CyFlow
®
Cube 8 | Operating Manual | May 2018 | Revision 032
When on the Report tab of the Workspace, click the Copy button to copy
the selected report objects for pasting into the report. Report items
cannot be pasted into other applications.
Delete: Click the button to delete the currently selected plots or region. If
the deleted plot has a region applied, deleting the plot also deletes the
region and removes the region from any gating logic. In this case, a
corresponding message box is displayed and you will have the option to
confirm or abort deleting the plot.
Select: Click the button to select groups of plots from a drop-down list:
Click the Select All option to select all the plots in the Plots area.
Click the Select Plots with Same Gate option to select all the plots that
have the same gate applied as the selected plot in the Plots area.
Click the Invert Selection option to select all the plots that are currently
not selected in the Plots area.
Click the Select Dual Parameter Plots or Select Histogram Plots
option to select all dual parameter plots or all histogram plots,
respectively.
Fonts: Click the button to open the Edit Fonts dialogue. In the pages of
this dialogue, you can change the font typeface and size for region
labels, plot titles, cell cycle and parameter names and scale labels in the
current Workspace. The pages are the same as in the software options
(see chapter Font pages on page 192).
12.4.4 Preview tab
The Preview tab provides controls for modifying the plots displayed in the
Previews area of the Workspace.
Preview group
The Preview group contains viewing options for the Previews area. The
buttons in this group are only available if a Worklist item or a Playlist item is
open in the Workspace. Selected buttons are highlighted in orange.
The buttons in the lower row of the Preview group contain filter options.
Filters affect which parameters, and therefore plots, are displayed in the
Previews area. The filters are used to selectively reduce the number of plots
displayed in the Previews area.
The Preview group contains the following buttons:
Show Previews: By default the button is selected, and previews of all
parameters are displayed in the Previews area. Clicking the button
