Tally Dascom 2600 2610
65
No. Description
Consists
of
Sub Part P/N Position Remark
9
Lower Housing
complete
532662 4.1.1
mounte
d
532183 Suspensions 9
532216 Housing Lower Part 10
540022 M4 Hexagon Nut 18
535035 Harness Power Switch Assy 20
535034 Harness Power Plug Assy 19
532124 Shielding Cover PSU 21
532123 Shielding Ground Plate 12
540048 M4x10 Screw 17
540020 M3x6 Screw 22
10 Tractor Assy 99992 4.2.1 Option
532041 Tractor Assy 30
11 Upper Friction 532663 4.2.1
532654 Upper Friction Assy 1
12 LF Motor 532593 4.2.1
532200 Stepper Motor Paper Feed 32
532203 Guide Ring 33
13 CR Motor 532594 4.2.1
532187 Clamp CR Motor 26
532192 Motor Damper 27
532082 Distance Holder 28
532196 Carriage Motor Assy 29
14 Sensor Kit 532595
535000
Paper End / TOF Sensor
Assy
4.2.1/4
535004 Head Gap Sensor Assy 4.2.1/39
535002
Paper Path Select Sensor
Assy
4.2.1/43
535023
Horizontal Position Sensor
Assy
4.2.4/6
532584 Paper Width Sensor Assy 4.2.4/5
