Tally Dascom 2600 2610
66
No. Description
Consists
of
Sub Part P/N Position Remark
15 Print Head 532596 4.2.4
&
Content
of Pos
14
532583 Print Head Assy 2
532249 Ribbon Mask 3
532144 Paper Guide Carriage 4
16 Ribbon Mask 532597 4.2.4
532249 Ribbon Mask 3
532144 Paper Guide Carriage 4
17 Head Cable 532664 4.2.4
532655 Print Head Cable Assy 1
18 Ribbon Drive 532599 4.2.4
540020 M3x6 Screw 21
532060 Ribbon Drive Assy 22
19 Carriage 532600 4.2.4
532199 Felt 8
532134 Carriage 9
20 Belt System 532665 4.2.4
532120 Mating Gear Assy 13
532121 Pulley Assy 25
540002 Ti ming Belt 26
21 Incremental Strip 532666 4.2.4
532135 Clamp Code Stripe 27
532142 Code Stripe 1/180" 28
