Acquiring Waveforms
3-44
CSA7000B Series & TDS7000B Series Instruments User Manual
Fast Acquisition display Normal DSO display
Figure 3- 14: Normal DSO and Fast Acquisition displays
Use the procedure that follows to set up Fast Acquisitions mode.
Overview To turn Fast Acquisitions on and off Control elements and resources
Prerequisites
1. The horizontal and vertical controls must be set up.
Triggering should also be set up.
See page page 3--29 for acquisition setup.
To Turn Fast Acquisitions
On and Off

Table of Contents

Other manuals for Tektronix CSA7404B

Questions and Answers:

Tektronix CSA7404B Specifications

General IconGeneral
Bandwidth4 GHz
Sample Rate20 GS/s
Sample Rate (Maximum)20 GS/s
Channels4
Vertical Resolution8 bits
Record Length100 Mpoints
Input CouplingAC, DC, GND
Power Supply100-240 VAC, 50/60 Hz
Vertical Sensitivity1 mV/div
Displaycolor LCD
Input Impedance1 MΩ
Maximum Input Voltage5 Vrms (50 Ω)
Trigger ModesEdge
InterfaceUSB, GPIB, Ethernet
