Tektronix CSA7404B User Manual

Appendix C: Menu Bar Commands
CSA7000B Series & TDS7000B Series Instruments User Manual
C-13
Table C- 8: Measure menu commands (Cont.)
Menu FunctionSubmenu
Annotation Standard, Detailed, Off,
Meas1, Meas 2, Meas 3,
Meas 4, Meas 5,
Meas 6, Meas 7, Meas 8
Allows you to select the type of measurement annotations, turn measurement
annotations off, or to select the measurement that you want to annotate.
Masks Commands
Table C--9 lists the commands available from the Masks menu (optional on
TDS7000B Series) on the menu bar.
Table C- 9: Masks menu commands
Menu Submenu Function
Mask Setup Displays the Mask Setup window that you use to create mask waveforms
Mask Type Displays the Type tab of the Mask Setup window that you use to select the type
of mask
Source Displays the Source tab of the Mask Setup window that you use to select the
source of mask
Tol erance Setup Displays the Tolerance Setup tab of the Mask Setup window that you use to set
up the mask margin tolerance
Pass/Fail Setup Displays the Pass/Fail Setup tab of the Mask Setup window that you use to set
up pass/fail testing
Pass/Fail Results Displays the Pass/Fail Results tab of the Mask Setup window that you use to
view test results
Mask On Toggles the mask on or off
Mask Controls Displays the Mask control window that you use to control mask pass/fai l testing
and display test results
Mask Configure Display, AutoSet,
Autofit...
Displays the Mask Configuration setup window that you use to configure the
display, autoset, and autofit features of mask testing
Mask Edit Setup Displays the Mask Edit Setup window that you use to create user masks
Mask Edit Controls Displays the Mask Edit control window that you use to edit user masks
Math Comman ds
Table C--10 lists the commands available from the Math menu on the menu bar.
