Appendix C: Menu Bar Commands
C-12
CSA7000B Series & TDS7000B Series Instruments User Manual
Table C- 8: Measure menu commands (Cont.)
Menu FunctionSubmenu
Time Rise Time, Fall Time,
Positive Width,
Negative Width, Period,
Frequency, Delay,
Pos Duty Cycle,
Neg Duty Cycle
Displays the selected measurement of the selected waveform
Comm Ext Ratio, Ext Ratio %,
Ext Ratio (dB),
Eye Height, Eye Width,
Eye Top, Eye Base,
Crossing %, Jitter Pk-Pk,
Jitter Rms,
Jitter 6 Sigma,
Noise Pk-Pk,
Noise RMS, S/N Ratio,
Cycle Distortion,
Quality factor
Displays the selected measurement of the selected waveform
More Area, Cycle Area, Phase,
Burst Width
Displays the selected measurement of the selected waveform
Histogram Measure-
ments
Waveform Count, Hits in
Box, Peak Hits, Median,
Maximum, Minimum,
Peak to Peak, Mean,
Standard Deviation,
Mean 1StdDev,
Mean 2StdDev,
Mean 3 StdDev
Displays the selected measurement of the histogram
Statisti cs Reset Statistics
Off,
Mean,
All
Statisti cs Controls
Resets measurement statistics
Displays the selected measurement statistics of current measurements
Displays the Statistics Controls window
Reference Levels Displays the Reference Levels setup window you use to set the reference levels
used by your measurements
Gating Cursor, Zoom 1, Zoom 2,
Zoom 3, Zoom 4, Off,
Gating
Allows you to select the gating method, turn off gating, or displays the
Measurement Gating control window you use to define the portion of the
waveform you want your measurements taken between
Waveform Histograms Reset Histograms
Horiz,
Vert,
Off,
Setup...
Resets histogram counting
Enables a horizontal histogram
Enables a vertical histogram
Turns off histograms
Displays the Waveform Histogram setup window you use to set histograms on
your waveforms
