Appendix A: Specifications
CSA7000B Series & TDS7000B Series Instruments User Manual
A-19
Table A- 5: Serial Trigger specifications (optional on TDS7000B Series)
Characteristic Description
Serial trigger number of bits 64
Serial trigger encoding types NRZ
nSerial trigger baud rate limits Up to 1.25 GBd
Serial trigger, serial word recognizer position
accuracy
Edge trigger, DC coupling, for signals having a slew rate at the trigger point of ≥ 0. 5
division/ns
Acquisition mode Error
Sample, Average ± (1 waveform interval + 200 ps)
Peak Detect, Envelope ± (2 waveform interval + 200 ps)
Clock recovery frequency range 1.5 MBd to 3.125 GBd. Above 1250 MHz the clock is only available internally as a
trigger source. Below 1250 MHz the clock is also available at the Recovered Clock
output along with regenerated data (CSA7000B Series only).
Clock recovery jitter, typical <0.25% bit period + 2 ps rms for PRBS data patterns.
<0.25% bit period + 1.2 ps rms for repeating 01 data patterns.
Clock recovery tracking/acquisition range, typical ±2% of requested baud
Minimum signal amplitude needed for clock
recovery, typical
1 division p-p up to 1.25 GBd
1.5 divisions p-p above 1.25 GBd
Table A- 6: Display specifications
Characteristic Description
Display type 210.4 mm (8.3 in) (W)× 157.8 mm (6.2 in) (H), 263 mm (10.4 in) diagonal, liquid
crystal active-matrix color display
Display resolution 1024 horizontal × 768 vertical pixels
Pixel pitch 0.2055 mm horizontal, 0.2055 mm vertical
Response time, typical 15 ms, white to black
Display refresh rate 59.94 frames per second
Viewing angle, typical Horizontal: 60 degrees left, 60 degrees right
Vertic al: 60 degrees up, 45 degrees down
Displayed intensity levels Each R-G-B input is 6 bits, giving 64 intensity levels of each color component
