Appendix C: Menu Bar Commands
C-14
CSA7000B Series & TDS7000B Series Instruments User Manual
Table C- 10: Math menu commands
Menu Submenu Function
Math Setup Displays the Math Setup control window that you use to create math waveforms
Display On/Off Toggles the display of math waveforms on and off
Position/Scale Displays the vertical Position and Scale control window that you can use to
change the vertical position and scale of waveforms
Label Displays a control window that you use to label your waveforms
Ch1--Ch2 Creates a predefined math waveform
Ch3--Ch4 Creates a predefined math waveform
Ch1*Ch2 Creat es a predefined math waveform
Ch3*Ch4 Creat es a predefined math waveform
Spectral Setup Displays the Spectral Math Setup control window that you use to create spectral
math waveforms
Magnitude Spectrum Creates a predefined magnitude spectral math waveform
Phase Spectrum Creates a predefined phase spectral math waveform
Spectral Controls Displays the Spectral Math controls window that you can use to control your
spectral math waveform
Set Math Averages Displays the Math Averaging controls window that you use to set up averaging
in math waveforms
Equation Editor Displays the Math Equation Editor setup window that you use to create math
waveforms
Application Commands
Table C--11 lists the commands available from the applications menu.
Table C- 11: Application menu commands
Menu Submenu Function
Restore Application Restores the minimized window of the currently running application
Installed application 1 Starts an installed application
Installed application 2
p
p
