Installation
CSA7000B Series & TDS7000B Series Instruments User Manual
1-19
CAUTION. Do not change the resolution or color settings for the internal LCD
monitor. The internal resolution must be 1024 x 768 and the color setting must
be True Color (24 bit).
11. Select OK to apply the settings. Select Yes to restart your instrument. After
the instrument restarts, the new monitor will display additional desktop area.
To make the best use of the new display area, do these additional steps to move
the Windows controls to the external monitor:
1. Click (and hold) on the Windows task bar in the area shown in Figure 1--7,
and then drag it upwards and toward the external monitor. The task bar will
first go to the side of the internal monitor, then to the side of the external
monitor, and finally to the bottom of the external monitor.
Click here to drag task bar.
Figure 1- 7: Drag area for Windows task bar
2. Release the mouse when the task bar is where you want it to be.
External monitor
Drop
Select all
3
Internal monitor
Drag
Figure 1- 8: Moving Windows desktop icons to the external monitor
