Tektronix CSA7404B User Manual

Installation
1-8
CSA7000B Series & TDS7000B Series Instruments User Manual
Mic......... .... ....
XVGA Out (PC only,
for dual display
operation) .........
Printer.............
RS-232..........
Network................
Keyboard ................
Mouse.................
USB..................
Compactdiskdrive.......
GPIB........
Instrument monitor
(large-screen instrument
display)...........
Description Icon/Label Locations
Audio line out.............
Removable hard drive or floppy . .
Audio line in .............
Figure 1- 1: Locations of peripheral connectors on rear panel
