Incoming Inspection
1-28
CSA7000B Series & TDS7000B Series Instruments User Manual
H From the Horiz/Acq menu, select Horizontal/Acquisition
Setup....
H Touch the Horizontal tab in the displayed control window.
H Touch the Delay Mode button to turn delay on.
H Double-touch the Horiz Delay control in the control window to
display the pop-up keypad. Touch the keypad buttons to set the
horizontal delay to 1ms, and then touch the ENTER key.
c. Verify the w aveform: Verify that a rising edge of the waveform is within
a few divisions of center screen.
d. Adjust the horizontal delay: Rotate the upper multipurpose knob to
change the horizontal delay setting. Verify that the rising edge shifts
horizontally. Rotate the front-panel horizontal POSITION knob. Verify
that this knob has the same effect (it also adjusts delay, but only when
delay mode is on).
e. Verify the delay toggle function:
H Rotate the front-panel horizontal POSITION knob to center the
rising edge horizontally on the screen.
H Change the horizontal SCALE to 40 ns/div. The rising edge of the
waveform should remain near the center graticule.
H Readjust the delay setting to position the rising edge 2 divisions to
the right of the center graticule line.
H Push the front-panel DELAY button s everal times to toggle delay off
and on and back off again. Verify that the display switches quickly
between two different points in time (the rising edge shifts horizon-
tally on the display).
9. Remove the test hookup: Disconnect the equipment from the channel input
and the probe compensation output.
Equipment
required
One BNC cable
One TCA-BNC TekConnect adapter
Prerequisites None
1. Initialize the instrument: Push the front-panel DEFAULT SETUP button.
2. Hook up the signal source: Connect the equipment to the CH 1 input as
shown in Figure 1--12.
3. Set up the instrument: Push the front-panel AUTOSET button.
Check Trigger Operation
