Creating and Using Math Waveforms
3- 202
CSA7000B Series & TDS7000B Series Instruments User Manual
1
0
Amplitude
Time
--90 dB side lobe
0
-- 8 0
dB
Frequency bins
-- 4 0
--120
0dB
--0.05
--0.1
Scallop loss is 0.0065 dB
Frequency bins
Figure 3- 61: Time and frequency domain graphs for the Flattop2 window
