Incoming Inspection
CSA7000B Series & TDS7000B Series Instruments User Manual
1-23
g. Confirm signal-path compensation returns passed status: Verify that the
word Pass appears in the instrument calibration control window.
2. Return to regular service: Touch the Close button to exit the instrument
calibration control window.
Functional Tests
The purpose of these procedures is to confirm that the instrument functions
properly. A list of required test equipment is shown on page 1--21.
NOTE. These procedures verify that the instrument features operate. They do not
verify that they operate within limits.
Therefore, when the instructions in the functional tests that follow call for you to
verify that a signal appears on-screen “that is about five divisions in amplitude”
or “has a period of about six horizontal divisions,” and so forth, do not
interpret the quantities given as limits.
NOTE. Do not make changes to the front-panel settings that are not called out in
the procedures. Each verification procedure will require you to set the instrument
to certain default settings before verifying functions. If you make changes to
these settings, other than those called out in the procedure, you may obtain
invalid results. In this case, redo the procedure from step 1.
When you are instructed to press a front-panel button or screen button, the
button may already be selected (its label will be highlighted). If this is the case,
it is not necessary to push the button.
Equipment
required
One BNC cable
One P7240 probe (P7260 probe for TDS7704B)
One 067-0405-xx (067-0484-xx for TDS7704B) probe calibration and
deskew fixture
Prerequisites None
1. Initialize the instrument: Push the front-panel DEFAULT SETUP button.
2. Hook up the signal source: Connect the equipment as shown in Figure 1--9
to the channel input you want to test (beginning with CH 1).
Check Vertical Operation
