Data Input/Output

CSA7000B Series & TDS7000B Series Instruments User Manual

3- 237

Overview Control elements and resourcesTo save a waveform (Cont.)

Select for

export

3. From the menu bar, select File, and then select Select

for Export.

The menu lists all available waveform, image, and

measurement types available for export:

H Full Screen to export a bitmap of all screen

contents

H Graticul e to export a bitmap of only the graticule

area

H Waveform to export waveform data

H Measurement s to export measurement data

Select setup for

export

4. From the menu bar, select File, and then select Export

Setup to display the Export Setup control window.
