MyScope
3- 258
CSA7000B Series & TDS7000B Series Instruments User Manual
Overview Control elements and resourcesTo create a new MyScope control window (Cont.)
Make control
selections
3. Click a control to preview it.
4. Double-click the control or click the + t o expand the
control list. (If there is no +, then the control cannot be
customized further.)
5. Clear the check boxes to remove any components that
you do not want included in the control.
Create a control
window
6. Click and drag the control to your MyScope control
window.
The control will snap to the nearest grid location when
you release the mouse. You can change the placement
of the control in your MyScope control window by
clicking and dragging.
To reconfigure a control, click and drag it back to the
preview window. Then select or clear the check boxes to
include or remove components in the control.
To Next Page
