Appendix A: Specifications
CSA7000B Series & TDS7000B Series Instruments User Manual
A-21
Table A- 7: Input/output port specifications (Cont.)
Characteristic Description
n Probe Compensator Output Front-panel BNC connector, requires Probe Cal Deskew Fixture for probe
attachment
Note: During probe calibration only, a relay switches a DC calibration voltage
to this output in place of the 1 kHz square wave. This voltage varies from
--10 V to +10 V with a source impedance less than 1 Ω and short circuit
current as high as 300 mA.
Output voltage Frequency
500 mV (from base to top) ± 20% into a 50 Ω
load (Vol = --500 mV, Voh = 0 V typical)
1 kHz ± 5%
1V(frombasetotop)± 20% into a 1 ΜΩ
load (Vol = --1.0 V, Voh = 0 V typical)
n Analog Signal Output amplitude BNC connector, provides a buffered version of the signal that is attached to
the channel 3 input when channel 3 is the trigger source
m
±
n
o
o
10 mV/div ± 20% into a 50 Ω load
Offset: between --100 mV and --170 mV into 50 Ω
n
og
gn
u
pu
n
w
,
p
.
z
n
o
o
n Auxiliary Output levels BNC connector, provides a TTL-compatible pulse (polarity selectable) for
each A or B trigger (selectable)
V
out
high V
out
low (true)
≥2.5 V into open circuit,
≥1.0 V into 50 Ω load
≤0.7 V with ≤4masink,
≤0.25 V into 50 Ω load
