Tektronix CSA7404B User Manual

Appendix B: Automatic Measurements Supported
CSA7000B Series & TDS7000B Series Instruments User Manual
B-13
Table B- 3: Supported measurements and their definition (Cont.)
Measurements Annotation descriptions
Comm
measurement
annotations
Noise P-P 1 box indicating the histogram boundaries.
In detailed mode, 4 horizontal arrows and 2 horizontal bars indicating the eye window left,
right, top, and base.
Noise RMS 1 box indicating the histogram boundaries.
In detailed mode, 4 horizontal arrows and 2 horizontal bars indicating the eye window left,
right, top, and base.
S/N Ratio 1 box indicating the histogram boundaries.
In detailed mode, 4 horizontal arrows and 2 horizontal bars indicating the eye window left,
right, top, and base.
Cyc Distortion 2 horizontal arrows indicating the time of the rise, time of the fall, and the reference level.
In detailed mode, 4 horizontal arrows and 2 horizontal bars indicating the eye window left,
right, top, and base. In detailed mode, 2 horizontal arrows indicating the position of
the crossings.
Q-Factor 4 horizontal arrows and 2 horizontal bars indicating the eye window left,
right, top, and base. In detailed mode, 2 horizontal bars indicating the eye top and base.
