Appendix C: Menu Bar Commands
C-8
CSA7000B Series & TDS7000B Series Instruments User Manual
Table C- 5: Trig menu commands (Cont.)
Menu FunctionSubmenu
Edge Setup Displays the Trigger Setup window and sets up the selected trigger type
Glitch Setup
Width Setup
Runt Setup
Window Setup
Timeout Setup
Transiti on Setup
Setup/Hold Setup
Logic Pattern Setup
Logic State Setup
Comm Setup (optional
on TDS7000B Series)
Serial Pattern Setup
(optional on TDS7000B
Series )
A-B Trigger Sequence
B Event (Delayed) Trig-
ger Setup
Holdoff Displays the trigger Holdoff control window you use to set trigger holdoff
Mode Displays the Trigger Mode control window you can use to select the trigger
mode, force a trigger, and set the trigger level to 50%
Run/Stop Displays the Run/Stop control window you can use to start and stop acquisi-
tions, control a single sequence of acquisitions, and display the acquisition
status
