Tektronix CSA7404B User Manual

Appendix C: Menu Bar Commands
C-10
CSA7000B Series & TDS7000B Series Instruments User Manual
Table C- 6: Display menu commands (Cont.)
Menu FunctionSubmenu
Record View Palette Normal,
Monochrome Gray,
Monochrome Green,
Tem perat ure Grading,
Spectral Grading
User
Choose Normal to use system colors for best viewing
Choose Green to display waveforms in shades of green
Choose Gray to display waveforms in shades of gray
Choose Temp (temperature) to display waveforms with the highest sample
density points appearing in warmer colors (reds)
Choose Spectral to display waveforms with the highest sample density points
appearing in blue shades
Choose User to display a control window to design your own colors
FastAcq/WfmD B Palette Normal,
Monochrome Green,
Monochrome Gray,
Tem perat ure Grading,
Spectral Grading,
User
Choose Normal to use system colors for best viewing
Choose Green to display fast acquisition and waveform database waveforms in
shades of green
Choose Gray to display fast acquisition and waveform database waveforms in
shades of gray
Choose Temp (temperature) to display fast acquisition and waveform database
waveforms with the highest sample density points appearing in warmer colors
(reds)
Choose Spectral to display fast acquisition and waveform database waveforms
with the highest sample density points appearing in blue shades
Choose User to display a control window to design your own colors
User Palette Displays a window that you use to set hue, lightness, and saturation for the
selected object. The Reset button allows you to reset the palette to factory
defaults. The Setup button displays the Color Setup window.
Display Trigger T Toggle on and off the display of a T at the trigger point
Waveform Display On Toggle on and off the waveform display
Display Date and Time Toggle on and off the display of the system date and time
Display Remote Toggl e on and off remote display support. VNC or pcAnywhere must be instal led
on the instrument and on the remote PC. When Display Remote is enabled,
display updates, control window accessing and menu items are slow.
