Analyzing waveforms Set up FLEXRAY search parameters
In this example, you need to set a Qualifier, Number of Bytes, Offset, and Data value (click the Edit
(see page 939) button). Optionally, you can also set the c omponent threshold levels through the Logic
Thresholds Se
tup button.
Click the Search For selections Indicator Bits (see page 354), Identifier (see page 355), Cycle Count (see
page 355), Header Fields (see page 356), Ident & Data (see page 356), End of Frame (see page 357),or
Error
(see page 357), to view their parameters.
What do you want to do next?
Learn about bus setups. (see page 95)
Search for indicator bits
354 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
