MyScope setups Open or edit a MyScope dialog box

Behavior

This dia

log box opens to the d efault directory

C:\Users\[Username]\Tek-

tronix\TekScope\MyScope

. If you saved MyScope control window ﬁles in another directory, click

the Look in drop-down list togotothatdirectory.

Clicking Open will open the selected MyScope control window, allowing you to add or delete controls.

NOTE. The only available ﬁle type is . tcw.

What do you want to do next?

Lear

n about the MyScope Setup and Edit control window.

(see page 379)

Learn about the Save MyScope File As dialog box. (see page 382)
