Trigger setups Set up a Runt trigger
Overview
Use the controls in this window to set up the Runt trigger parameters.
To use
For information on the controls, click the buttons.
NOTE. The Trigger Runt screen on DPO/DSA Series instrument is same as that on an MSO/DPO5000, and
MSO70000C S
eries instrument except for the source selec tion and Trigger if Runt Qualification options.
In some instruments, the source selection is a drop-down list and the Trigger if Runt Qualification option
has Occurs
and Logic.
In other instruments the source selection includes a combo list and a Select button. The Trigger if Runt
Qualifica
tion option has Occurs, Logic, and Occurs And.
The following Trigger Runt s creen appears on MSO70000C Series instruments:
The following Trigger Runt screen appears on MSO/DPO5000 Series instruments:
NOTE. Logic qualification option is not available on DPO5000 and MSO5000 Series instruments.
428 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
