Trigger setups Set up a Runt trigger
Behavior
Use the Upper Level and Lower Level threshold controls to set the voltage ranges that define a valid pulse.
Runt pulses are s hort pulses that cross one threshold but fail to cross a second threshold before crossing the
first threshold again. The pulse widths are measured at the voltage level specified by the level controls.
Thesepulsescanalsobequalified by time, by the logical state of other channels, or by a bus pattern
(MSO70000C Series only). When you click o n the trigger window controls, the trigger graphic
(see
page 386) shows
the trigger sequence.
What do you want to do next?
Learn m ore about other trigger types. (see page 386)
Return to the Trigger Setup control window. (see page 385)
