G10 MAINTENANCE PROCEDURES
This section contains the following information:
Field Replaceable Units
Removing and Replacing a PEM
Replacing the Fan Tray
Replacing G10 Chassis Air Filters
G10 Blade Removal/Replacement Procedures
Replacing G10 Shelf Managers (SHMMs)
Serial Over LAN (SOL) Support
G10 Probe and Array Start Up/Shut Down Sequence
Field Replaceable Units
The following tables lists the Field Replaceable Units (FRUs) for the G10 and storage array.
Chassis
3U DC Chassis with Shelf Manager
G10 SHMMs (replaced in pairs)
G10 DC Power Entry Module (PEM)
AC Power Entry Module (PEM)
G10 Fan Tray (Front)
G10 Fan Tray (Rear)
G10 Air Filters
Blades and RTMs
IIC100 8x 1GB Blade set includes the following:
AMC Carrier Blade CAB100
LPC100 AMC
FPC100 AMC
SRM100 RTM
