G10 Installation Guide 7.13.2 143
C
Rev. 005-140228
Serial Over LAN (SOL) Support
The G10 probe provides Serial Over LAN (SOL) support that enables administrators to access
remote serial console ports securely on the IAP and IIC blades. The SOL access helps
administrators troubleshoot and debug hardware issues, view console messages, and monitor
blade boot-up sequences. Use of Serial Over LAN eliminates the need to maintain a terminal
server with the probes.
Perform the following to lau
n
ch an SOL session:
Step Action
1. From any workstation, open a Command window.
2. Type ssh <Public IP address
of either G10 SHMM> to log in to the
G10 probe.
3. Perform one of the following at the SHMM command line prompt:
To log in to the IAP blade, type iconsole 1.1.
To log in to the IIC blade, type iconsole 1.2.
A console window opens from which you can view console messages and
blad
e activities.
G10 Probe and Array Start Up/Shut Down Sequence
Tektronix recommends powering the probes and associated arrays on and off in a specific
sequence. The equipment can withstand unexpected power outages; but a proper power
on/off sequence should be followed whenever possible.
Start Up Procedure
Perform the following steps in the specific order listed to properly power up the G10 probe(s)
and storage enclosures.
Step Action
1. G10 AC Units only: Ensure that the G10 AC power cables are NOT
connected to the rack power outlet.
2. Turn on the circuit breakers at the power distribution panel.
3. Power on the storage arrays. Power on th
e e
xpansion enclosures first and then
the controller enclosures.
a. Press the power switches to the ON position on both power modules at the
ba
ck of each en
closure.
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
