10. Wait about 10 minutes for the IAP blade to boot up. The OOS LED transitions
from RED (board booting) to AMBER (applications starting) to OFF, indicating
that the probe is up.
If LEDs are behaving differently than described in this procedure, contact Tektronix
Communications Customer Support.
11. For multiprobe configurations, after the G10 Primary Chassis is powered up
successfully, turn on the power to the G10 Expansion Chassis. Verify the LEDs
on the expansion chassis as described in Step 6 through Step 9 in this
procedure.
Shut Down Procedure
Perform the following steps in the specific order listed to properly power down the G10
probe(s) and storage enclosures.
Step Action
1. In multiprobe configurations, start the power down procedure with the
expansion chassis by performing the following:
 Initiate the hot-swap mode for both IIC or IAP blades. Refer to Removing or
Resetting the IIC100 or IIC200 or Removing or Resetting the IAP200/
IAP320 for details. Note th
at no action is required for the Rear-Transition
Modules.
 Wait until the hot-swap LED is solid blue.
 Unseat both blades approximately 2 inches from the backplane.
2. On the primar
y or standalone chassis, initiate hot-swap mode for the IIC and
wait until the hot-swap LED is solid blue. Note that no action is required for the
Rear-Transition Module.
3. On the prima
r
y or standalone chassis, initiate the hot-swap mode for the IAP
blade and wait until the hot-swap LED is solid blue.
4. Unseat the IIC and IAP on the primary or
st
andalone chassis approximately 2
inches from the backplane.
5. Turn off the power to the ex
p
ansion chassis:
 AC Units: Disconnect the AC power cables from the rack power outlets.
 DC Units: Press the ON/OFF switch to the OFF position on both PEMs on
the front of the G10 chassis.
6. Turn off the power to the primary or
st
andalone chassis:
 AC Units: Disconnect the AC power cables from the rack power outlets.
 DC Units: Press the ON/OFF switch to the OFF position on both PEMs on
the front of the G10 chassis.
