G10 Installation Guide 7.13.2 150
C
Rev. 005-140228
- Connect the AC power cables to the AC power connectors on the rear of
the storage enclosure.
Enclosures are shipped with a grounding-type (three-wire) power cord. To reduce the risk of
electric shock, always plug the cord into a grounded power outlet. Site wiring must include
an earth ground connection to the AC power source. Grounding must comply with local,
national, or other applicable government codes and regulations.
Bezel (Air Filter) Procedures
The storage enclosure has a bezel assembly that attaches to the front of the storage array and
contains the air filter. Refer to the following procedures for details about the bezel assembly:
Installing the Bezel
Removing the Air Filter
Replacing the Air Filter
General guidelines concerning air
filters in inventory:
Replacement air filter storage:
Air filters in inventory shou
ld be stored in an environment that is cool, dry, and dark.
Heat, humidity, and ultraviolet light can damage air filters.
Replacement air filter inventory on hand:
Purchase a cost-effective quantity of replacement air filters
to maintain a sufficient
inventories for no more than a few months. This approach enables you to avoid stock-
outs and mitigate inventory loss due to shrinkage.
Installing the Bezel
Perform the following steps to install the storage enclosure bezel assembly.
Step Action
1. Put on an ESD wrist strap.
Electrostatic discharge can damage circuits or shorten their life. Before touching the blade
or electronic components, ensure that you are working in an ESD-safe environment.
2. Remove the bezel assembly from its box and verify that it includes the installed
air filter subassembly.
3. Align the bezel assembly with the front o
f
the enclosure so the integrated ear
covers slide onto the push-fit ball studs, while taking care to guide the LED
indicators through ear-cover openings (Figure C.39).
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
