G10 Installation Guide 7.13.2 87
5
Connect G10 to the Monitored Network
Rev. 005-140228
10G Ethernet Cabling for Optical Taps/Splitters
Perform the following to connect Ethernet cabling to the monitored network using optical taps/
splitters.
Step Action
1. Use Figure 5.8 and Table 5.6 to connect monitored network cables using
optical taps or splitters to the G10 10G Ethernet connections. In this
configur
ation the TX ports are not used.
Figure 5.8 - 10G Ethernet Connections - Optical Taps/Splitters
B
OUT
A
IN
A
OUT
B
IN
A TAP
TX
B TAP
RX
B
OUT
A
IN
A
OUT
B
IN
A TAP
TX
B TAP
RX
Tx
Rx
Monitored
Node A
Monitored
Node B
A IN
B OUT
A OUT
B IN
A TAP B TAP
TX RX
Monitored Interface
"Link 2"
10GbE 4
10GbE 3
GbE 2
GbE 1
10GbE 2
10GbE 1
Tx
Rx
Tx
Rx
Tx
Rx
Tx
Rx
10G Ports on
TRM100 RTM
Monitored Interface
"Link 1"
Optical Tap/Splitter
Optical Tap/Splitter
Optical Tap/Splitter
SysClk 1
SysClk 1
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
