G10 Installation Guide 7.13.2 17
Install Hardware and
Power Cabling
BEFORE YOU BEGIN
Installation of the G10 units must be performed by persons with advanced technical
knowledge of electrical wiring. The installer will be stripping wires, attaching lugs,
and wiring several components together. Wiring the components incorrectly can
result in damage to the G10 and other components.
You will need the following supplies for G10 installations:
A Phillips head screwdriver #1 and #2 (10-inch length or longer recommended for two-post rack installs)
A Flat head screwdriver
A laptop or PC with an Ethernet cable to connect to the G10 probe, which requires Web access for probe
configuration
Rackmount screws for mounting equipment to the rack/cabinet
(Tektronix provides brackets for two-post and four-post racks)
Wire cutter
Wire stripper
Wire crimp tool
Power cables for connecting the fuse panel to the power supply
(The fuse panel input terminals accept up to #2 AWG two-hole lug connectors on 1/4” screw terminals
with 5/8” spacing—torque to 62 in-lbs)
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
