Tektronix GeoProbe G10 Installation Guide

G10 Installation Guide 7.13.2 96 
A
Rev. 005-140228
DC POWER REQUIREMENTS
Table A.1 lists the DC power requirements for the GeoProbe G10 and SAS storage
enclosures. All probe and disk enclosure power and
chassis ground cabling use 12AWG cable
or larger.
Tektronix equipment, cables, and wiring diagrams comply with industry standard DC
electrical color coding. Please ensure proper cabling if your equipment and cabling uses
nonstandard DC electrical color coding. Improper cabling can cause damage to equipment
or personal injury. Contact Tektronix to request specially labeled power cables (-48V = Red,
Return = Black) for the G10 chassis and the storage enclosures.
AC POWER REQUIREMENTS
Table A.1 lists the AC power requirements for the GeoProbe G10 and SAS storage
enclosures. All probe and disk enclosure power and chas
sis ground cabling will use 12AWG
cable or larger.
Table A.1 - DC Power Requirements
Equipment VDC Fuse Watts
G10 (IIC100 and IAP100) -40 to -72VDC 15A max 430W typical, 600W max
G10 (IIC100 and IAP200) -40 to -72VDC 15A max 470W typical, 600W max
G10 (IIC200 and IAP200) -40 to -72VDC 15A max 495W typical, 600W max
G10 (IIC200 and IAP320) -40 to -72VDC 15A max 495W typical, 600W max
SA100R RAID Storage Enclosure -40 to -72VDC 15A max 280W typical, 500W max
SA100J JBOD Storage Enclosure -40 to -72VDC 15A max 280W typical, 500W max
SA200R RAID Storage Enclosure
a
-40 to -72VDC 15A max 420W typical, 500W max
SA200J/SA210J JBOD Storage Enclosure
b
-40 to -72VDC 15A max 255W typical, 500W max
a. For Storage Enclosure and 24 900G drives (SA200J) or 12 4TB drives (SA210J).
Table A.2 - AC Power Requirements
Equipment VAC Fuse Watts
G10 (IIC100 and IAP100) 100 to 240 VAC 6A max 470W typical, 600W max
G10 (IIC100 and IAP200) 100 to 240 VAC 6A max 520W typical, 600W max
G10 (IIC200 and IAP200) 100 to 240 VAC 6A max 545W typical, 600W max
G10 (IIC200 and IAP320) 100 to 240 VAC 6A max 545W typical, 600W max
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
