G10 Installation Guide 7.13.2 97
A
Rev. 005-140228
DEFAULT PORT SETTINGS
Table A.2 lists the default port settings for the G10 probe.
SA100R RAID Storage Enclosure 100 to 240 VAC 5A max 280W typical, 500W max
SA100J JBOD Storage Enclosure 100 to 240 VAC 5A max 280W typical, 500W max
SA200R RAID Storage Enclosure
a
100 to 240 VAC 5A max 420W typical, 500W max
SA200J/SA210J JBOD Storage
Enclosure
b
100 to 240 VAC 5A max 255W typical, 500W max
a. For Storage Enclosure and 24 900G drives (SA200J) or 12 4TB drives (SA210J).
Table A.2 - AC Power Requirements (Continued)
Equipment VAC Fuse Watts
Table A.3 - Default Port Settings
G10 Component Ports Supported
Spe
eds
Autonegotiation?
LPC200 (IIC200 1G 1G No
LPC200 (IIC200) 10G/1G 10G/1G No
LPC100 (IIC100) All 1G No
SRM200 10G 10G No
TRM100 10G 10G No
PRM300 ETH A-D 10G/1G/100M Yes
PRM200 ETH A-D 10G/1G/100M Yes
IAP320 ETH 1G/100M Yes
IAP200 ETH 1G/100M Yes
IAP100
a
a. Not supported on Control Plane or Media probes.
ETH A, B 1G/100M Yes
SHMM MGMT 100M Yes
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
