Power On G10 and Configure Network Connectivity
Rev. 005-140228
Public Subnet Mask Provide the corresponding subnet mask for the Public IP Address. After
the subnet mask has been entered in the Configuration GUI, the system
populates the SHMM A Subnet Mask and SHMM B Subnet Mask
fields with the same value.
Public IP Gateway Provide the corresponding IP gateway for the Public IP Address. After
the
IP ga
teway has been entered in the Configuration GUI, the system
populates the SHMM A IP Gateway and SHMM B IP Gateway fields
with the same value.
Backplane Subnet Provide the IP subnet for the probe’s backplane. It must be a class-B
sub
n
et; ensure that this subnet does not overlap any of the subnets (IP
addresses) on the public interface.
SHMM A IP Address (OAM
Inte
rface)
Provide the IP address to be used for Operations and Maintenance
(LAN/WAN) access to the probe’s A Shelf Manager.
SHMM A Subnet Mask This field is populated with the same subnet mask
you enter for the
Public Subnet Mask. The field is editable.
SHMM A IP Gateway This field is populated with the same IP gateway you enter for the
Public IP Gateway. The field is editable.
SHMM B IP Address (OAM
Inte
rface)
Provide the IP address to be used for Operations and Maintenance
(LAN/WAN) access to the probe’s B Shelf Manager.
SHMM B Subnet Mask This field is populated with the same subnet mask
you enter for the
Public Subnet Mask. The field is editable.
SHMM B IP Gateway This field is populated with the same IP gateway you enter for the
Public IP Gateway. The field is editable.
Iris Server IP Address Provide the IP address of the Iris Server to which this
probe will
connect.
Time Zone You will select the time zone in which the probe is deploy
ed.
NTP Server IP Address Provide the IP address of the server that this probe will
use for time
synchronization.
DNS Search List (optional) Enter the search list for host-name lookup.
DNS Primary Server I
P Address Provide the IP address of the primary DNS server this probe will use.
DNS Secondary Server IP Address Provide the IP address of the secondary DNS server this probe
will use.
Table 4.1 - Network Connectivity Parameters (Continued)
Parameter D
escription
