G10 Installation Guide 7.13.2 79
5
Connect G10 to the Monitored Network
Rev. 005-140228
2. After the cables are connected, verify that the ACT and LNK LEDs are on.
3. Call Tektronix Service and Delivery to confirm the successful G10 installation
(refer
to page 2).
Table 5.2 - G10 Ethernet Connections - Optical Taps/Splitters
M
onitor
ed Network G10 Ethernet Connections
Monitored Interface 1 “Link 1” B Tap (RX) GbE 1 RX (right)
A Tap (TX) GbE 2 RX (left)
Monitored Interface 2 “Link 2” B Tap (RX) 1/10GbE 5 RX (left)
A Tap (TX) 1/10GbE 6 RX (left)
Monitored Interface 3 “Link 3” B Tap (RX) 1/10GbE 7 RX (left)
A Tap (TX) 1/10GbE 8 RX (left)
Monitored Interface 4 “Link 4” B Tap (RX) GbE 3 RX (right)
A Tap (TX) GbE 4 RX (left)
