G10 Installation Guide 7.13.2 81
5
Connect G10 to the Monitored Network
Rev. 005-140228
2. After the cables are connected, verify that the ACT and LNK LEDs under each
GbE port are ON.
3. Call Tektronix Service and Delivery to confirm the successful G10 installation
(r
efer
to page 2).
Monitored Interface 2 “Link 2” TX GbE 2 RX (left)
RX GbE 2 TX (right)
Mon
itored Interface 3 “Link 3” TX 1/10GbE 5 RX (left)
RX 1/10GbE 5 TX (right)
Monitored Interface 4 “Link 4” TX 1/10GbE 6 RX (left)
RX 1/10GbE 6 TX (right)
Monitored Interface 5 “Link 5” TX 1/10GbE 7 RX (left)
RX 1/10GbE 7 TX (right)
Monitored Interface 6 “Link 6” TX 1/10GbE 8 RX (left)
RX 1/10GbE 8 TX (right)
Monitored Interface 7 “Link 7” TX GbE 3 RX (right)
RX GbE 3 TX (left)
Monitored Interface 8 “Link 8” TX GbE 4 RX (left)
RX GbE 4 TX (right)
Table 5.3 - G10 Ethernet Connections - Mirror/Span (Continued)
Monitored Network G10 Ethernet Connections
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
