Performance Verification
4-10 SPG600 & SPG300 Sync Pulse Generators Service Manual
4. Press the Measure button on the video measurement set to open the Measure
mode display.
5. Touch the Level Meter soft key.
6. Press the Menu button to display the Level Meter main menu.
7. Touch the Measure Position soft key to display the Measure Position
submenu.
8. Touch the Dc Cpl. ABS. Meas. soft key.
9. Verify that the blanking level is within the range of +50 mV to -50 mV.
10. Move the BNC cable connection from the CH 1 connector to the CH 2
connector on the sync pulse generator.
11. Repeat step 9.
12. Move the BNC cable connection from the CH 2 connector to the CH 3
connector on the sync pulse generator.
13. Repeat step 9.
14. Move the BNC cable connection from the CH 3 connector to the CH 4
connector on the sync pulse generator.
15. Repeat step 9.
SPG600 Option 02 Only. Perform steps 16 through 23 if Option 02 is installed in
your SPG600.
16. Move the BNC cable connection from the CH 4 connector to the CH 5
connector on the sync pulse generator.
17. Repeat step 9.
18. Move the BNC cable connection from the CH 5 connector to the CH 6
connector on the sync pulse generator.
19. Repeat step 9.
20. Move the BNC cable connection from the CH 6 connector to the CH 7
connector on the sync pulse generator.
21. Repeat step 9.
22. Move the BNC cable connection from the CH 7 connector to the CH 8
connector on the sync pulse generator.
23. Repeat step 9.
To Next Page
