Teledyne RIVERPRO - WC - Correlation Threshold; WD - Data Out

RiverPro and RioPro ADCP Guide October 2017
EAR-Controlled Technology Subject to Restrictions Contained on the Cover Page.
Page 113
H-Gain W-BW L-Gain W-BW
Lag Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4
0 1000 1000 1000 1000 1000 1000 1000 1000
1 749 742 777 754 840 827 827 824
2 332 297 405 332 530 498 500 491
3 250 213 186 207 97 66 69 52
4 11 57 56 33 8 8 17 6
5 145 73 58 62 3 7 8 7
6 54 11 15 9 2 11 2 7
7 29 11 19 8 15 2 10 10
H-Gain N-BW L-Gain N-BW
Lag Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4
0 1000 1000 1000 1000 1000 1000 1000 1000
1 832 861 856 854 833 829 827 830
2 498 573 561 557 507 499 494 499
3 80 127 157 111 60 54 57 55
4 70 33 80 19 15 8 3 4
5 68 35 67 4 8 2 17 6
6 53 15 56 16 4 6 9 4
7 57 23 58 19 17 4 6 10
H-Gain W-BW L-Gain W-BW H-Gain N-BW L-Gain N-BW
Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4
RSSI Noise Floor (counts)
54 52 48 48 44 46 46 44 40 41 40 39 35 38 38 37
>pt3 2
Receive Path Test (Linear):
SNR (dB):
H-Gain W-BW L-Gain W-BW
Lag Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4
0 999.9 999.9 999.9 999.9 999.9 999.9 999.9 999.9
1 4.7 4.7 5.5 4.9 7.3 6.7 6.8 6.7
2 -3.3 -3.6 -1.6 -3.1 0.6 -0.1 -0.1 -0.2
3 -5.1 -5.9 -6.3 -6.2 -8.8 -11.8 -11.5 -12.2
4 -20.3 -12.1 -12.3 -12.0 -19.1 -17.5 -19.7 -17.4
5 -7.7 -10.7 -11.9 -11.0 -20.8 -18.9 -21.4 -21.0
6 -12.0 -20.6 -21.3 -21.1 -22.9 -26.2 -20.8 -19.5
7 -13.8 -20.4 -16.2 -21.8 -20.9 -25.0 -21.2 -20.7
H-Gain N-BW L-Gain N-BW
Lag Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4
0 999.9 999.9 999.9 999.9 999.9 999.9 999.9 999.9
1 7.0 7.9 7.8 7.7 7.0 6.8 6.8 6.9
2 0.0 1.3 1.1 1.0 0.2 -0.1 -0.1 0.0
3 -10.4 -7.7 -7.2 -8.7 -11.7 -12.7 -11.8 -12.1
4 -11.0 -14.5 -10.5 -17.6 -22.0 -22.4 -18.4 -18.5
5 -10.8 -16.5 -9.7 -18.3 -18.9 -24.8 -20.6 -21.8
6 -11.6 -16.3 -11.1 -19.5 -23.1 -20.6 -19.9 -24.2
7 -12.0 -17.7 -11.2 -18.3 -22.1 -22.3 -24.0 -23.7
H-Gain W-BW L-Gain W-BW H-Gain N-BW L-Gain N-BW
Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4 Bm1 Bm2 Bm3 Bm4
RSSI Noise Floor (counts)
54 51 48 48 43 46 46 44 40 41 40 39 35 38 38 37
>
PT11 = FRAM Test
>pt11
FRAM test...PASS
>
PT12 = RAM Test
>pt12
