Variable Leader Data Format
BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
1 VARIABLE LEADER ID
80h
2
00h
3
ENSEMBLE NUMBER
LSB
4
MSB
5 RTC YEAR {TS}
6 RTC MONTH {TS}
7 RTC DAY {TS}
8 RTC HOUR {TS}
9 RTC MINUTE {TS}
10 RTC SECOND {TS}
11 RTC HUNDREDTHS {TS}
12 ENSEMBLE # MSB
13 BIT FAULT
14 BIT COUNT
15
SPEED OF SOUND {EC}
LSB
16
MSB
17
DEPTH OF TRANSDUCER {ED}
LSB
18
MSB
19
HEADING {EH}
LSB
20
MSB
21
PITCH (TILT 1) {EP}
LSB
22
MSB
23
ROLL (TILT 2) {ER}
LSB
24
MSB
25
SALINITY {ES}
LSB
26
MSB
27
TEMPERATURE {ET}
LSB
28
MSB
29 MPT MINUTES
30 MPT SECONDS
31 MPT HUNDREDTHS
32 HDG STD DEV
33 PITCH STD DEV
34 ROLL STD DEV
