Bottom-Track Data Format
BIT POSITIONS
BYTE 7/S 6 5 4 3 2 1 0
1
BOTTOM-TRACK ID
LSB 00h
2 MSB 06h
3
BT PINGS PER ENSEMBLE {BP}
LSB
4 MSB
5
BT DELAY BEFORE RE-ACQUIRE
LSB
6 MSB
7 BT CORR MAG MIN
8 BT EVAL AMP MIN
9 BT PERCENT GOOD MIN
10 BT MODE {BM}
11
BT ERR VEL MAX
LSB
12 MSB
13
Reserved
14
15
16
17
BEAM#1 BT RANGE
LSB
18 MSB
19
BEAM#2 BT RANGE
LSB
20 MSB
21
BEAM#3 BT RANGE
LSB
22 MSB
23
BEAM#4 BT RANGE
LSB
24 MSB
25
BEAM#1 BT VEL
LSB
26 MSB
27
BEAM#2 BT VEL
LSB
28 MSB
29
BEAM#3 BT VEL
LSB
30 MSB
31
BEAM#4 BT VEL
LSB
32 MSB
33 BEAM#1 BT CORR.
34 BEAM#2 BT CORR.
35 BEAM#3 BT CORR.
36 BEAM#4 BT CORR.
