Teledyne RIVERPRO - Figure 30. Fixed Leader Data Format

RiverPro and RioPro ADCP Guide October 2017
EAR-Controlled Technology Subject to Restrictions Contained on the Cover Page.
Page 141
BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
37
SPARE
LSB
38
MSB
39 FALSE TARGET THRESH {WA}
40 SPARE
41
TRANSMIT LAG DISTANCE
LSB
42
MSB
43
CPU BOARD SERIAL NUMBER
LSB
↓
↓
50
MSB
51
SYSTEM BANDWIDTH
LSB
52
MSB
53 SYSTEM POWER
54 SPARE
55
INSTRUMENT SERIAL NUMBER
MSB
↓
58
LSB
59 BEAM ANGLE
See Table 19 for a description of the fields
Figure 30. Fixed Leader Data Format
