Fixed Leader Data Format
BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
1 FIXED LEADER ID
LSB 00h
2
MSB 00h
3 CPU F/W VER.
4 CPU F/W REV.
5
SYSTEM CONFIGURATION
LSB
6
MSB
7 REAL/SIM FLAG
8 LAG LENGTH
9 NUMBER OF BEAMS
10 NUMBER OF CELLS
11
PINGS PER ENSEMBLE
LSB
12
MSB
13
DEPTH CELL LENGTH
LSB
14
MSB
15
BLANK AFTER TRANSMIT
LSB
16
MSB
17 PROFILING MODE
18 LOW CORR THRESH
19 NO. CODE REPS
20 PERCENT GOOD
21
ERROR VELOCITY MAXIMUM {WE}
LSB
22
MSB
23 TPP MINUTES
24 TPP SECONDS
25 TPP HUNDREDTHS {TP}
26 COORDINATE TRANSFORM {EX}
27 HEADING ALIGNMENT {EA}
LSB
28
MSB
29
HEADING BIAS {EB}
LSB
30
MSB
31 SENSOR SOURCE {EZ}
32 SENSORS AVAILABLE
33
BIN 1 DISTANCE
34
35
XMIT PULSE LENGTH BASED ON
LSB
36
MSB
