Table 43: Beam Correction Matrix Format
Hex Digit Binary
Byte
Field Description
1-4 1-2 ID Code Stores the Beam Correction Matrix identification word ID 0x3200h.
LSB=00, MSB=32
3-4 Row 1 Col 1 Beam Calibration Matrix scaled int 2 bytes per entry for 16 entries
LSB=0.0001
↓ ↓ ↓ ↓
33-34 Row 4 Col 4 Beam Calibration Matrix
This data is output based on the setting of the WD command.
Reserved BIT Data Format
BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
1
RESERVED FOR TRDI USE
LSB
2 MSB
Figure 46. Reserved BIT Data Format
Table 44: Reserved for TRDI Format
Hex Digit Binary Byte Field Description
1-4 1,2 Reserved for TRDI’s
use
This field is for TRDI (internal use only).
Checksum Data Format
BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
1
CHECKSUM DATA
LSB
2 MSB
Figure 47. Checksum Data Format
Table 45: Checksum Data Format
Hex Digit Binary Byte Field Description
1-4 1,2 Checksum Data This field contains a modulo 65536 checksum. If the sum is 12345678, then it is di-
vided by 65536, and the remainder is output; For example, 12345678 / 65536 =
188.3800964 = 188 + 24910/65536, so the number 24910, converted to hex as 614E
would be output.
An easier way to compute the checksum is using the sum 12345678; converted to
hex it is the number 00BC614E. The least-significant four hex digits are output; i.e.
614E.
