Vertical Beam Profile Leader Format
BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
1
VERTICAL BEAM PROFILE LEADER ID
LSB 01
2 MSB 0F
3
NUMBER OF BINS
4
5
NUMBER OF PINGS PER ENSEMBLE
6
7
BIN SIZE
8
9
DISTANCE TO BIN 1 MIDDLE
10
11
RESERVED
12
13
TRANSMIT LENGTH
14
15
LAG LENGTH
16
17
NUMBER OF CODE ELEMENTS TRANSMITTED
18
19
RESERVED
↓ ↓
40
Figure 41. Vertical Beam Profile Leader Format
