RiverPro and RioPro ADCP Guide October 2017
EAR-Controlled Technology Subject to Restrictions Contained on the Cover Page.
Page 165
BIT POSITIONS
BYTE 7/S 6 5 4 3 2 1 0
73.
BEAM 4 Bin 1 Mid
LSB
74. MSB
75. BEAM 4 Code Reps
76.
BEAM 4 Transmit Length
LSB
77. MSB
78.
BEAM 4 Lag Length
LSB
79. MSB
80. BEAM 4 Transmit Bandwidth
81. BEAM 4 Receiver Bandwidth
82.
BEAM 4 Min Ping Interval
LSB
83. MSB
84. Reserved
Figure 38. Automatic Mode Setup Data
Table 33: Automatic Mode Setup Format
Hex Digit Binary
Byte
Field Description
1-4 1,2 ID Code Stores the status data identification word ID 4401h
5,6 3 Beam Count Stores the Beam Count
7,8 4 Mode Stores the Beam 1 setup
9-12 5-6 Depth Stores the Beam 1 Depth in cm
13,14 7 Data Ping Count Stores the Beam 1 Data Ping Count
15,16 8 Ping Type Stores the Beam 1 Ping Type 0=mode 2, 1=p-p, 2=coherent
17-20 9-10 Cell Count Stores the Beam 1 Cell Count
21-24 11-12 Cell Size Stores the Beam 1 cell size in cm
25-28 13-14 Bin 1 Mid Stores the Beam 1 Bin 1 Mid in cm
29,30 15 Code Reps Stores the Beam 1 number of Code Reps
31-34 16-17 Transmit Length Stores the Beam 1 Transmit Length in cm
35-38 18-19 Lag Length Stores the Beam 1 Lag Length in cm
39,40 20 Transmit Bandwidth Stores the Beam 1 Transmit Bandwidth
41,42 21 Receiver Bandwidth Stores the Beam 1 Receiver Bandwidth
43-46 22-23 Min Ping Interval Stores the Beam 1 Min Ping Interval in ms
47,48 24 Mode Stores the Beam 2 setup
49-52 25-26 Depth Stores the Beam 2 Depth in cm
53,54 27 Data Ping Count Stores the Beam 2 Data Ping Count
55,56 28 Ping Type Stores the Beam 2 Ping Type 0=mode 2, 1=p-p, 2=coherent
57-60 29-30 Cell Count Stores the Beam 2 Cell Count
61-64 31-32 Cell Size Stores the Beam 2 cell size in cm
