October 2017 RiverPro and RioPro ADCP Guide
Page 166
EAR-Controlled Technology Subject to Restrictions Contained on the Cover Page.
Table 33: Automatic Mode Setup Format
Hex Digit Binary
Byte
Field Description
65-68 33-34 Bin 1 Mid Stores the Beam 2 Bin 1 Mid in cm
69,70 35 Code Reps Stores the Beam 2 number of Code Reps
71-74 36-37 Transmit Length Stores the Beam 2 Transmit Length in cm
75-78 38-39 Lag Length Stores the Beam 2 Lag Length in cm
79,80 40 Transmit Bandwidth Stores the Beam 2 Transmit Bandwidth
81,82 41 Receiver Bandwidth Stores the Beam 2 Receiver Bandwidth
83-86 42-43 Min Ping Interval Stores the Beam 2 Min Ping Interval in ms
87,88 44 Mode Stores the Beam 3 setup
89-92 45-46 Depth Stores the Beam 3 Depth in cm
93,94 47 Data Ping Count Stores the Beam 3 Data Ping Count
95,96 48 Ping Type Stores the Beam 3 Ping Type 0=mode 2, 1=p-p, 2=coherent
97-100 49-50 Cell Count Stores the Beam 3 Cell Count
101-104 51-52 Cell Size Stores the Beam 3 cell size in cm
105-108 53-54 Bin 1 Mid Stores the Beam 3 Bin 1 Mid in cm
109,110 55 Code Reps Stores the Beam 3 number of Code Reps
111-114 56-57 Transmit Length Stores the Beam 3 Transmit Length in cm
115-118 58-59 Lag Length Stores the Beam 3 Lag Length in cm
119,120 60 Transmit Bandwidth Stores the Beam 3 Transmit Bandwidth
121,122 61 Receiver Bandwidth Stores the Beam 3 Receiver Bandwidth
123-126 62-63 Min Ping Interval Stores the Beam 3 Min Ping Interval in ms
127,128 64 Mode Stores the Beam 4 setup
129-132 65-66 Depth Stores the Beam 4 Depth in cm
133,134 67 Data Ping Count Stores the Beam 4 Data Ping Count
135,136 68 Ping Type Stores the Beam 4 Ping Type 0=mode 2, 1=p-p, 2=coherent
137-140 69-70 Cell Count Stores the Beam 4 Cell Count
141-144 71-72 Cell Size Stores the Beam 4 cell size in cm
145-148 73-74 Bin 1 Mid Stores the Beam 4 Bin 1 Mid in cm
149,150 75 Code Reps Stores the Beam 4 number of Code Reps
151-154 76-77 Transmit Length Stores the Beam 4 Transmit Length in cm
155-158
78-79 Lag Length Stores the Beam 4 Lag Length in cm
159,160 80 Transmit Bandwidth Stores the Beam 4 Transmit Bandwidth
161,162 81 Receiver Bandwidth Stores the Beam 4 Receiver Bandwidth
163-166 82-83 Min Ping Interval Stores the Beam 4 Min Ping Interval in ms
167,168 84 Reserved Reserved
