Table 38: Vertical Beam Profile Correlation Magnitude Data Format
Hex Digit Binary Byte Field Description
1-4 1,2 ID Code Stores the vertical beam profile correlation magnitude data identification word
(LSB=00, MSB=0B).
5,6 3 Depth Cell 1, Field 1 Stores correlation magnitude data for depth cell #1, beam #1. See above.
7 – 404 4 – 202 Cells 2 – 200 (if
used)
These fields store correlation magnitude data for depth cells 2 through 200 for all
four beams. These fields follow the same format as listed above for depth cell 1.
Table 39: Vertical Beam Profile Echo Intensity Data Format
Hex Digit Binary Byte Field Description
1 – 4 1,2 ID Code Stores the vertical beam profile echo intensity data identification word (LSB=00,
MSB=0C).
5,6 3 Depth Cell 1, Field 1 Stores echo intensity data for depth cell #1, beam #1. See above.
7 – 404 4 – 202 Cells 2 – 200 (if
used)
These fields store echo intensity data for depth cells 2 through 200 for all four
beams. These fields follow the same format as listed above for depth cell 1.
Table 40: Vertical Beam Profile Percent-Good Data Format
Hex Digit Binary
Byte
Field Description
1-4 1,2 ID Code Stores the vertical beam profile percent-good data identification word (LSB=00,
MSB=0D).
5,6 3 Depth cell 1, Field 1 Stores percent-good data for depth cell #1, field 1. See above.
7 – 404 4 – 202 Cells 2 – 200 (if used) These fields store percent-good data for depth cells 2 through 200, following the
same format as listed above for depth cell 1.
Table 41: Vertical Beam Profile Status Data Format
Hex Digit Binary
Byte
Field Description
1-4 1,2 ID Code Stores the vertical beam profile status data identification word (LSB=00, MSB=0E).
5,6 3 Depth cell 1, Field 1 Stores status data for depth cell #1, field 1. 1=good, 0=bad
7 – 404 4 – 202 Cells 2 – 200 (if used) These fields store status data for depth cells 2 through 200, following the same for-
mat as listed above for depth cell 1.
