Firmware Status Data
BIT POSITIONS
BYTE 7 6 5 4 3 2 1 0
1
ID CODE
LSB 00
2 MSB 44
3 VERSION ALPHA
4
VERSION BRANCH
5
6
7
8
9
10
11
12
13
14
15
16
17
18
TEST DATA
19
20
TEST SWITCHES
21
22 RESERVED
Figure 39. Firmware Status Data
Table 34: Firmware Status Format
Hex Digit Binary
Byte
Field Description
1-4 1-2 ID Code Stores the status data identification word ID 4400h.
4,6 3 Version Alpha ASCII character
7-34 4-17 Version Branch ASCII character string
35-38 18-19 Test Data Word Test Data Selected
39-42 20-21 Test Switches Word Test Switch Selected
43,45 22 Reserved Reserved
