2. System Overview, Features, and Specifications System Manual
Page 2-8 8/09 76.7300FP11/2, Rev A
Specifications
2.20 Refer to the following subsections for system requirements, system
dimensions, and environmental specifications of the Tellabs 7345 Switch and the
Tellabs 7325 Switch.
System Dimensions
2.21 Refer to Table 2.1, page 2-8 for physical characteristics of the Tellabs
7345 shelf and to Table 2.2, page 2-8 for physical characteristics of the Tellabs
7325 Switch.
Table 2.1 Tellabs 7345 Shelf Dimensions
Characteristic Value
Height 3.48 inches (88.5 mm)
Width 18.9 inches (480 mm)
Base Depth 11.0 inches (279.4 mm)
Weight 8.42 pounds (3.82 Kg) chassis only
14.31 pounds (6.49 Kg) chassis with full complement of modules (two
10G Switch Modules, two Power Supply Unit modules, one CMCC
Module, one Fan Tray, and one CMCC front panel)
Table 2.2 Tellabs 7325 Switch Dimensions
Characteristic Value
Height 1.75 inches (44.45 mm)
Width 17.5 inches (444.5 mm)
Depth 11.0 inches (279.4 mm)
Weight 7.8 pounds (3.6 Kg)
