System Manual 4. System Components
76.7300FP11/2, Rev A 8/09 Page 2-29
10G Switch Module Physical Specifications
Weight 2.43 pounds (1.1 kg)
Dimensions Height: 1.63 inches (41.5 mm)
Depth: 8.53 inches (216.67 mm)
Width: 10.87 inches (276 mm)
Table 4.2 10G Switch Module LED Descriptions
LED Status Description
Active green The module is active and provisioned to the UP state.
green flashing Initial bootup and software download.
red Module is faulted (in the DOWN operational state).
off Module is in standby.
Power green Both -48V power supplies are present and both -48V
fuses are intact.
red The module is faulted (in the DOWN operational state).
off The module is inactive or the LED is not functional.
Fault red The module is faulted.
red flashing The module is in reset or software download.
off No fault exists or the LED is not functional.
Sync Not used.
XFP Port LED
Ports 1–2
and
SFP Port LED
Ports 3–26
green Port facility isprovisioned to the UP state, no facility faults
exist.
red An LAGPF, LOS, or LOSYNC condition has been
detected or SFP/XFP is not present (when port facility is
in the UP admin state and in the DOWN operational
state).
amber Port facility is provisioned to the DOWN state.
amber flashing Loopback on this port is in progress.
off Port facility is not provisioned.
