System Manual 4. System Components
76.7300FP11/2, Rev A 8/09 Page 2-31
CMCC Physical Specifications
Weight 0.44 pounds (0.2 kg)
Dimensions Height: 0.80 inches (20.25 mm)
Depth: 7.95 inches (202 mm)
Width: 4.57 inches (116 mm)
Table 4.3 CMCC LED Descriptions
LED Status Description
Power/Status off The module has no power or the module is not functional.
green Normal condition.
red Faulted or the module is performing a self-test.
green flashing Module is booting and initializing application software.
Active/Standby green The module is active.
off The module has no power or the LED is not functional.
Reset
(push button)
N/A Resets the module.
Safe Removal Not used.
Act green Indicates activity/traffic on the management connection.
Link green Indicates that link is up.
Ack Not used.
A
(Critical)
red Critical alarm occurred.
off No alarm condition.
B
(Major)
yellow Major alarm occurred.
off No alarm condition.
H
(Minor)
yellow Minor alarm occurred.
off No alarm condition.
W
(Warning)
Not used.
